Plasma Cutter TL-50C | Non-Touch Pilot Arc High Frequency Start

Plasma Cutter TL-50C | Non-Touch Pilot Arc High Frequency Start

$229.99
$299.99 $229.99
Sale Sold out
Shipping calculated at checkout.

SPECIFICATION

· Input Voltage:110(120)V/220(230)V

· Input Current:23.2A(110V)/21.6A(220V)

· Rated Duty Cycle:60%(50A)

· Protection Class:IP21S

· Insulation Class:F

· Output Voltage:96V

· Max. Output Current:50A

HIGHLIGHT FEATURES

1. Non-Touch pilot ARC: Efficiently cuts through rough, painted, and rusty surfaces. Cut without touching the metal. Better cutting quality and longer consumable life.

2. Powerful: Up to 50A output, 60% Duty Cycle, maximum 1/2" Clean Cut.

3. Amperage Adjustable: 15A~40A @110V / 20A-50A @220V

4. Digital Display：visible to cutting current, convenient to adjust the amp.

5. Multi-application: widely used for cutting stainless steel, alloy steel, mild steel, copper, and other metal materials.

6. Dual Voltage Design: allows the machine to run directly on 110 V power or on 220 V with the use of a power adapter.

Free return and replace within 30 days. We make sure you have enough time to explore the machine.

The average shipping time is 5 days.

We have warehouses located in southern California and northern Kentucky to manage all shipping and returns.

We cover all quality-related issues in one year and provide lifetime technical support for other problems.

For orders made on Tooliom website only.

support@tooliom.com

View full details

CUT TL-50C

· Non-touch Polit ARC, the torch head does not need to touch the metal plate, then it will start arc. Can cut though rough, painted, and rusty surfaces efficiently longer consumable life.

· Up tp 50A output, can handle 1/2" Clean Cut at 220v.

· Auto-voltage can be operated at 110V or 220V input power.

· Equipped with a digital display, can easily read the current data.

· Recommend 25A breaker at 220V, 40A breaker at 110V.

· Suggested air pressure 220V@73PSI 50 Amps, 110V@65PSI 40 Amps.

  • NON-TOUCH POLIT ARC

    · Incorporates non-touch pilot arc cutting processes, cutting effect is very ideal and can finish the work regardless if the material is very rough, rusty, greasy, dirty, spray painted, etc. Meanwhile longer consumable life.

  • 110V or 220V Dual Voltage

    · With 50A heavy duty plug adapter, auto-voltage adapts to 110 V - 220 V input power.

  • Digital Data Display

    · DC output digital LCD display, can see the current data clearly and easier.

  • Cutting Thickness

    · Input voltage 110VDC, Cutting current 40Amps output, 13/64 inch clean-cut, 25/64 inch max cutting thickness

    · Input voltage 220VDC, Cutting current 50Amps output, 15/64 inch clean-cut, 31/64 inch max cutting thickness.

  • USE

    · Equipped with a heavy-duty cooling fan to help heat dissipation.

    · Inner comes with automatic thermal overload protection.

    · Powered by standard 110(120)V household current, using an adapter can be connected to 220(230)V circuit.

  • Package Included

    · 1*TL-50C Plasma Cutter

    · 1*Plasma Cutting Torch

    · 1*110 Volt to 220 Volt power adapter

    · 1*10' Ground Clamp

    · 1*Gas Hose 8'

    · 1*Air Pressure Regular

    · 1*Electrode *3, Nozzle *2, Extend Tips *3

    · 1*Instruction

Free Return and Replace

Why not give it a try?

30days money-back guarantee!

4.7
63 reviews
5
 44
4
 19
3
 0
2
 0
1
 0

Customer Photos

  • featured image
  • featured image
  • featured image
  • featured image
  • featured image
Showing 1 - 10 of 63 reviews
g
Gulab Dutta
Verified Purchase

Have only got to use a couple times.

First off I have only used this product a couple times so far. With that being said so far so good! Love how small and convenient it is.

  • Is this helpful?
c
Chantal Stewart
Verified Purchase

Works great

I'm just a hobby welder and don't use it alot this thing works great my new favorite tool cuts quicker the any saw for the money don't think y I u could go wrong thanks

  • Is this helpful?
Oscar Anderson Oscar Anderson
Verified Purchase

Cuts 3/8 like butter

My higher priced cutter went south and I didn't want to spend another $1k+ on a replacement. I checked Amazon and read some reviews and ultimately picked the Toolium 50.I have made +/- 200 cuts on 3/8 plate with zero issues. If the machine acts up I'll report back

  • Cuts 3/8 like butter
  • Is this helpful?
g
Gregory Roberts
Verified Purchase

Nice little machine.

Nice little machine. Could use a better air hose in box. I haven't used it a lot yet, but so far so good. Seller is good to work with.

  • Is this helpful?
j
Jackson Davis
Verified Purchase

Impressive

For the price, it's very impressive. I cut some stainless steel, and a piece of 3/8" snow plow blade. Have to go pretty slow on that thickness, but I'll rarely need to.

  • Is this helpful?
w
Wale Adewale
Verified Purchase

Well built machine

Very easy machine to learn, as a beginner hobby welder this item works very well.

  • Well built machine
  • Is this helpful?
m
Maryjane Donnelly
Verified Purchase

Recommend running on 220/240 Volts

I used this machine to cut through a 1/4 steel plate that I made to fit on top of my range to use as a gridde. In my opinion this is about as good as it gets for the price point. I recommend upgrading the air hoses to a more heavy duty grade and the regulator threads will need teflon tape to prevent air leaks. I have no doubt this will cut thicker than 1/4 inch steel. Overall I am very pleased with its performance and hope this machine will provide long service life. If you would like more info, I have posted a video on the youtube channel "Southern Home Talk"

  • Recommend running on 220/240 Volts
  • Is this helpful?
m
Marshall Smitham
Verified Purchase

Very easy for the first plasma I have owned. Makes projects so much faster!

This was easy to setup. Does not take a very big compressor. I have a 3.0 cfm and it's more than enough. It cuts as steady as your hand is. Cuts nice fine lines once settings are correct for that meal.One thing, it does require a large circuit breaker for 110volt. 35 amp. Lots of house don't have this. The average house has 30 amps or less for breakers. It blows 30amp breakers in about 5 minutes or less. Once I got my extension cord so I can share my dryer outlet, it I hooked it up to 220 volts and wow, talk about powerful. Had to dial it way back because on 220 volts, it's very powerful.BUY BUY BUY, Good machine.

  • Is this helpful?
e
Efe Aminat
Verified Purchase

Came delivered complete

When used on high voltage it preformed better than we expected. Had difficulty with low voltage mode

  • Is this helpful?
c
Chyna Zboncak
Verified Purchase

Got a bad unit initially but tech support was quick to make it right

Received as a Christmas gift (which i requested), had always wanted a plasma cutter but as mentioned elsewhere even HF's is nearly $700, so figured would take a chance. And seeing it was dual voltage and non contact, were massive selling points for this particular model.Packaging is great, visual quality is good for everything except maybe the hose fittings and hose itself, both could be higher quality, but are easy (and cheap) enough to replace, it did leak even with the clamps tightened to the max, replaced with my own fittings, and fixed that. Then attempted a couple test runs of various metal thicknesses. A good ground is a MUST for 110v especially. 240v worked like a knife through butter, 110v was sporadic, air flow was more critical on 110v than 240v.That being said on my second use of the Plasma Cutter, a couple weeks later. I heard a POP, my 40 AMP circuit breaker to the circuit blew as well. Reset the breaker, but the Plasma Cutter never worked again. I contacted support, as it was past my return window at Amazon by this point. Surprisingly they were very fast to warranty the unit. I did have to send in the broken one, and package it up myself, and pay the shipping, but they promptly shipped me out a brand new one, within a week.Additionally a day before the new Plasma Cutter arrived they actually sent me a welding helmet as well. I guess as a goodwill gesture. Which was appreciated. (Helmet was pretty good quality as well, better than the HF one i already had)Since unboxing and setting up the new one, I have used it a few times, on 110v and it hasn't had any device issues. Again a good ground is critical to get a good arc especially at lower power levels. Also 110v does have a tendency to over power the circuit breakers for the house, as they all are only 20 AMP (as most 110v home circuits are) So if its thin metal or if you are only using 110v at about 1/2 -2/3 max power its good. (They do mention this in the documentation as well ) but above 2/3 power, if you have 240v available it's probably best to use that.As far as longevity it will be yet to be determined as I don't do a whole lot of cutting, but this second unit has already exceeded the original. So over all happy with the purchase and performance.

  • Is this helpful?
